DNH Explosion Proof Zone II Horn loudspeakers, model: HS-15 EExIIN, 8 Ohm
Material/Color Aluminium / RAL7035
Mounting Bracket
Termination E-chamber / Screw terminal
Weight 2.7 kg
IP Rating IP67
Min/Max amb temp -50 °C / 50 °C
Rated power 15 W
SPL 1W/1m: 107 db
SPL Rated Power 118 db
Effective freq. Range 350 - 7500 Hz
Dispersion (-6dB) 1kHz / 4kHz 140° / 30°
Options Color / Impedance / Label
13,921,200 ₫ 13921200.0 VND
DNH Explosion Proof Zone II Horn loudspeakers, model: HS-15 EExIINT, 100V
Material/Color Aluminium / RAL7035
Mounting Bracket
Termination E-chamber / Screw terminal
Weight 2.7 kg
IP Rating IP67
Min/Max amb temp -50 °C / 50 °C
Rated power 15 W
SPL 1W/1m: 107 db
SPL Rated Power 118 db
Effective freq. Range 350 - 7500 Hz
Dispersion (-6dB) 1kHz / 4kHz 140° / 30°
Options Color / Impedance / Label
16,351,200 ₫ 16351200.0 VND
DNH FM Explosion Proof Horn loudspeakers, model: HS-15 ExdFM, 8 Ohm
Material / Color ..............Aluminum alloy SS4263 / RAL 7031
Mounting................................................................Bracket
Termination ............................................... Screw terminals
Weight w/ transformer ............................................. 2,8 kg
IP-rating (UL equivalent) ................................. (4X & 6) 67
Max / min amb temp.....................................40 °C / -20 °C
Rated / max power .........................................15 W / 15 W
SPL 1W/1m............................................................. 105 dB
SPL rated power ..................................................... 116 dB
Effective freq range...................................... 410 – 7000 Hz
Dispersion (-6dB) 1kHz / 4kHz ............................ 140° / 40°
Directivity factor, Q (1 kHz) ...........................................2,6
Options ......................................Impedances, colors, labels
25,023,600 ₫ 25023600.0 VND
